Products Description
Typical Application :
Widely used in bedside DR, vehicle DR, orthopedic surgery, fever clinic, first aid, private clinic, community hospital and township health center.
Feature
1. Using high frequency inverter technology , high voltage output stability, can obtain good image quality.
2. The compact design .small dimension and low weight make it easy to carry in different areas and places
3.With three exposure control methods: Wireless/Hand brake/Operation panel
4. Fault self-diagnosis,self-protection.
5. With flexible digital interface and SDK protocol, users can go deep into the core programming control and adapt to different Detectors.
6. Automatic measurement of shooting distance and thickness, and then automatically generate exposure conditions
Widely used in bedside DR, vehicle DR, orthopedic surgery, fever clinic, first aid, private clinic, community hospital and township health center.
Feature
1. Using high frequency inverter technology , high voltage output stability, can obtain good image quality.
2. The compact design .small dimension and low weight make it easy to carry in different areas and places
3.With three exposure control methods: Wireless/Hand brake/Operation panel
4. Fault self-diagnosis,self-protection.
5. With flexible digital interface and SDK protocol, users can go deep into the core programming control and adapt to different Detectors.
6. Automatic measurement of shooting distance and thickness, and then automatically generate exposure conditions
Model |
HFX-05PR |
|||||
|
Max Output Power |
5.6kW |
|||||
|
Power Capacity |
100kV@50mA |
|||||
|
Radio graphic kV Range |
40-50kV |
40-60kV |
40-80kV |
40-100kV |
40-100kV |
40-110kV |
|
Radio graphic mA Range |
100 mA |
80 mA |
63mA |
50mA |
40mA |
32mA |
mAs Range |
0.32-315mAs |
|||||
|
Exposure Time Range |
0.01-6.3s |
|||||
|
Operating Frequency |
≥ 30kHz |
|||||
|
Input Power Type |
220VAC+10%,50Hz/60Hz Or 110VAC+10%,50Hz/60HZ |
|||||
Dimensions |
520mmx330mmx250mm(LWH) |
|||||
Weight |
21kg |
|||||
|
Inverter Method |
PWM(pulse width modulation) |
|||||
Workshop
Customer Feedbacks
Related Products
Company Profile
FAQ
1. What about the price level? We are confident that our prices are competitive compared with those at the same quality level, since we have stayed in this filed more than 20 years. And we always adhere to the principle of provide top quality products with competitive prices. We have already established our good fame in many countries, especially in Africa, Middle East, European, Asia and South American through year after year efforts. 2. Why we find some prices are very high compared with some other supplier, and from the picture or it's model number, all looks the same? As China is still a developing country, there are only a few products with patent rights, and copy products I spread very fast in the market. Of course, the prices of those copy products with cheap material and less quality control are relatively cheaper. 3. What is time of delivery? Since our products are produced according to each specific order, the delivery period will be 15 days after confirmation of order. If it is small or sample order, please do check with us about whether we have ready goods in stock to make delivery as soon as possible. 4. What about quality assurance? We offer one year warranty period beginning from the time of shipment for medical equipment, Per minor problems, we can provide free spare parts for replacements, Per serious problems, we can make replacement of free charge. 5. What is payment terms? T/T, Credit Card, L/C, Western Union, PayPal, MoneyGram.
