Products Description

USE: General photograph, Ray-filter photograph

Main characteristics:

1.Single bed with single bulb
2.High-voltage system is of split structure,with high-voltage generator of full-wave rectification, independent X-ray tube unit,large output power and reliable and stable operation(tangential type pipe is covered)
3.Be equipped with the manostat for the filament of X-ray tube and space complementary to ensure the stable and exact output
4.Be equipped with capacity limit protective circuit kV, mA and s interlock limit protection
5.Design according to the electric mechanism of middle- size machine,with complete and reasonable function
6.Power voltage(V),photograph kilovolt(kV)infinitely variable control
7.The photographic flat bad has a vibrating Ray-filter
8.The timer circuit grades according to R10 priority coefficient has an exact time control
9.The pillar has only the bottom track, with easy installation

ITEM	C O N T E N T	I N D E X
Demand of power supply	Voltage	Single phase 220V/380V±10%
	Frequency	50Hz±1Hz
	Capacity	10kVA
	Internal resistance	220V:0.69380V:2Ω
Photography	Voltage	50-90kV
	Current	(small focus):16mA, (big focus):32mA、63mA、100mA
	Time	0.04-6.3s(0.04-6.3s,22 grades together)
high-voltage transformer unit	Capacity	7kVA
	Max.DC output voltage	90kV
	Max.DC output current	100mA
X-Ray tube	Model	XD4-2.9/100
	Focus	(small focus):1.8mm,(big focus):4.3mm
(DG1) Photographic bed	Bed face(L×W×H)	1900mm×695mm×700mm
	Ray-filter	(Grid density):N28
		convergence distance):100cm
		(Grid ratio):r8
Pillar of X-Ray source unit	moving in length	>1350mm
	moving in breadth	>360mm
	moving up and down	720-1800mm
Max size cassette for photograph		365mm×432mm(14”×17”)
Gross weight	700kg	Weight	550kg
External dimensions		2180mm×800mm×1130mm

MAX VOLUME OF PHOTOGRAPH:
Focus of X-Ray tube	(mA)photograph Current	(kVp)Max photograph Voltagec	(S)Max allowable exposure time
Small focus	15	90	6.3
Big focus	30	90	6.3
	60	90	6.3
	100	85	2.5
