Products Description
Modular high-voltage generator
High-frequency and high-voltage generator, KV, mAs closed loop control, steady output; Real-time control by microprocessor, guarantee the accuracy and repeatability of dosage.
Wheel
Select the imported large-size wheel, being quiet during moving, portable. Even in narrow space, it also can through steadily and rapidly.
Inverter
Overvoltage and undervoltage protection for high-voltage, overcurrent protection for tube current, output overloading protection, fault prompt.
X-ray Picture
Adoption of high-frequency and high-voltage technology, fusion with computer control technology, precise parameter and excellent ray quality, provide the clear image for you.
Touch screen
Large-size touch colorful liquid crystal display is adopted to be served as human-computer interface, with double CPU control, intuitive operation interface, colorful screen display, easy leaning and easy use. The operation interface style may be set based on user's favorite.
Power Supply：220V±10%;
Input power：7.5kW； 9KVA PLX101C
Mains frequency：50Hz±1Hz；
Source resistance：≤0.5Ω；
Main technical parameters：
Power modules： 30kHz；
Filament frequency： 20kHz； 1KHz PLX101C
Focus： 1.5mm
Max. generator output： 5.3kW；
Max. X-ray tube voltage:120KV
kV range：40～120kV；
mAs range：1～200mAs； 1-160mAs PLX101C
Max. mA :100mA
Main parameters of mechanical parts：
X ray tube vertical motion range：≥500～1950mm； 500～1850mm；PLX101C
X ray source components around the cross arm vertical rotation：≥±90°；
Exposure size：≥430mm×430mm(SID=100cm)；
Machine main function：
Fault detection error prompt functions；
ARP Human anatomy program function；
Parameter calibration function；
Technical Specifications
High-frequency and high-voltage generator, KV, mAs closed loop control, steady output; Real-time control by microprocessor, guarantee the accuracy and repeatability of dosage.
Wheel
Select the imported large-size wheel, being quiet during moving, portable. Even in narrow space, it also can through steadily and rapidly.
Inverter
Overvoltage and undervoltage protection for high-voltage, overcurrent protection for tube current, output overloading protection, fault prompt.
X-ray Picture
Adoption of high-frequency and high-voltage technology, fusion with computer control technology, precise parameter and excellent ray quality, provide the clear image for you.
Touch screen
Large-size touch colorful liquid crystal display is adopted to be served as human-computer interface, with double CPU control, intuitive operation interface, colorful screen display, easy leaning and easy use. The operation interface style may be set based on user's favorite.
Power Supply：220V±10%;
Input power：7.5kW； 9KVA PLX101C
Mains frequency：50Hz±1Hz；
Source resistance：≤0.5Ω；
Main technical parameters：
Power modules： 30kHz；
Filament frequency： 20kHz； 1KHz PLX101C
Focus： 1.5mm
Max. generator output： 5.3kW；
Max. X-ray tube voltage:120KV
kV range：40～120kV；
mAs range：1～200mAs； 1-160mAs PLX101C
Max. mA :100mA
Main parameters of mechanical parts：
X ray tube vertical motion range：≥500～1950mm； 500～1850mm；PLX101C
X ray source components around the cross arm vertical rotation：≥±90°；
Exposure size：≥430mm×430mm(SID=100cm)；
Machine main function：
Fault detection error prompt functions；
ARP Human anatomy program function；
Parameter calibration function；
Technical Specifications
Power Supply |
220V±10% |
Input power |
7.5kW |
Main frequency |
50Hz±1Hz |
Source resistance |
≤0.5Ω |
Power modules |
30kHz |
Filament frequency |
20kHz |
Focus |
1.5mm |
Max. generator output |
5.3kW |
Max. X-ray tube voltage |
120KV |
kV range |
40～120kV |
mAs range |
1～200mAs |
Max. mA |
100mA |
X ray tube vertical motion range |
≥500～1950mm |
X ray source components around the cross arm vertical rotation |
≥±90° |
Exposure size |
≥430mm×430mm(SID=100cm) |
Workshop
Customer Feedbacks
Related Products
Company Profile
FAQ
1. What about the price level? We are confident that our prices are competitive compared with those at the same quality level, since we have stayed in this filed more than 20 years. And we always adhere to the principle of provide top quality products with competitive prices. We have already established our good fame in many countries, especially in Africa, Middle East, European, Asia and South American through year after year efforts. 2. Why we find some prices are very high compared with some other supplier, and from the picture or it's model number, all looks the same? As China is still a developing country, there are only a few products with patent rights, and copy products I spread very fast in the market. Of course, the prices of those copy products with cheap material and less quality control are relatively cheaper. 3. What is time of delivery? Since our products are produced according to each specific order, the delivery period will be 15 days after confirmation of order. If it is small or sample order, please do check with us about whether we have ready goods in stock to make delivery as soon as possible. 4. What about quality assurance? We offer one year warranty period beginning from the time of shipment for medical equipment, Per minor problems, we can provide free spare parts for replacements, Per serious problems, we can make replacement of free charge. 5. What is payment terms? T/T, Credit Card, L/C, Western Union, PayPal, MoneyGram.
