Products Description
Features:
1.Dimensions: 520(mm)×300(mm)×1920(mm) ±3%;
2.Dimensions of cassette holder: 440(mm)×520(mm) ±3%;
3.The lifting range of the cassette holder (distance from the center to the ground): ≥ 1100mm±3%, and the minimum distance from the center to the ground should be ≤450mm±3%;
4.Camera Specifications:
It should be able to store photographic cassettes of various specifications of 20.3 cm×25.4cm～35.6cm×43.2cm (8″×10″～14″×17″), and the deviation of the positioning marks should be ≤5mm;
5. The starting force of the cassette holder moving up and down: ≤50N±5%;
6. The braking resistance of the cassette frame moving up and down: ≥100N±5%;
7. The safety system of the balance wire rope in the photo frame> 8;
8. The cassette frame moves up and down, and the handbrake brakes;
9. The safety system of the balance wire rope in the photo frame> 8;
Product parameters
1.Dimensions: 520(mm)×300(mm)×1920(mm) ±3%;
2.Dimensions of cassette holder: 440(mm)×520(mm) ±3%;
3.The lifting range of the cassette holder (distance from the center to the ground): ≥ 1100mm±3%, and the minimum distance from the center to the ground should be ≤450mm±3%;
4.Camera Specifications:
It should be able to store photographic cassettes of various specifications of 20.3 cm×25.4cm～35.6cm×43.2cm (8″×10″～14″×17″), and the deviation of the positioning marks should be ≤5mm;
5. The starting force of the cassette holder moving up and down: ≤50N±5%;
6. The braking resistance of the cassette frame moving up and down: ≥100N±5%;
7. The safety system of the balance wire rope in the photo frame> 8;
8. The cassette frame moves up and down, and the handbrake brakes;
9. The safety system of the balance wire rope in the photo frame> 8;
Product parameters
Project |
Parameter content |
Wire Grid Specifications |
≥15″×18″ |
Grid ratio |
R: 10:1 |
Grid density |
N: 40L/cm [103 lines/inch] (60L/cm) [154 lines/inch] |
Convergence Distance |
F : ≥150cm |
Total attenuation factor |
≤2.5 |
